[P115W-D] KISAN PATHBLAZER HEADLIGHT MODULATOR (FOR GL1800/GL1500)

$164.95
3 reviews Write a Review
SKU:
P115W-D-(LED)
Shipping:
Calculated at Checkout

P115W-D LED VERSION

KISAN TECH PATHBLAZER HEADLIGHT MODULATOR (FOR GL1800/GL1500)

Dual headlights Master/Slave Set for H4 or Japanese H7 bulbs (with P43t expander) that plug into 3-pin sockets.

It is available in the New Compact Style with optional LED software.

New Style P115W-D is totally self-contained. There are no hidden boxes or switches. There are no wires to cut or splice. The New Style is is more compact and uses latest generation electronics.

New Style P115W-D  is designed for a motorcycle with dual 3-pin H4, or a Japanese H7 2-pin (with p43t expander to plug into H4 socket) headlamps - like GoldWing.

This dual unit has (1) Master and (1) Slave. Master supplies the modulation pulses to the Slave, so they are fully synchronized. Each modulator is 1.05 (26mm) round, and requires no additional room after it's plugged on the back of the bulb because of the pig-tail design.

LED Headlight Bulbs: Special software program controls the modulation with PWM mode for a "softer" transition.

p115WD-inst

pathBlazer circuit modulates the hi-beam current - from 100% ON to about 17% OFF. This is accomplished by using a p-channel MOSFET, which is inherently safe. The MOSFET is designed to fail in the ON state. For additional safety, the circuits DO NOT utilize the lo-beam whatsoever!

MAX power rating is 115 watts. DO NOT EXCEED!


P115W-D comes with a detachable daylight sensor, which plugs into the Master of the pathBlazer. A Sync wire then plugs into the Slave.

The daylight sensor functions as a switch; it stops modulation when it cannot see enough daylight. Since the internal circuitry is controlled by a microprocessor, it allows for customizable features.

Programmable Daylight Sensor

3-Click programming: If you turn the high beam on and then turn the ignition on (3) times quickly, the sequence is interpreted as an active command to change the sensitivity. Software version v.823A allows 8 linear steps between the high and low end.

The daylight sensor has a low frequency filter to avoid false triggering. Please note that florescent lamps may not trigger the sensor - it needs constant incandescent light.

pathBlazer uses a soft-switching technique. It throttles the current flow through the bulb filament, so that there's no "thermal shock" due to a sudden inrush of current, which can damage the bulb filament or shorten its life considerably. This is far superior than maintaining a small voltage!

Select hi-beam to modulate - as long as there's sufficient daylight. If you enter a tunnel or if it gets dark, it will stop the modulation of the hi-beam and stay ON steady. Select lo-beam to end modulation.

DIY logo

Installation does not require any special tools. Everything needed to complete the job is in the product package. Follow the steps described here and refer to the Installation Manual enclosed in the product package.

Installation videos for Goldwing models with standard bulbs and LED bulbs are viewable on our YouTube channel. Or you can search for them directly on YouTube.





For CALIFORNIA residents only:

WARNING: This product contains chemicals including DEHP, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information visit https://www.p65warnings.ca.gov

FITMENT:
FOR HONDA GL1800/GL1500
INSTALLATION:
PLUG N PLAY
PACKAGE CONTENTS:
(2) MODULATORS, INTALLATION GUIDE
30 DAY FROM DATE OF PURCHASE RETURN IF UNUSED/IN SALABLE CONDITION. 30 DAY FROM DATE OF PURCHASE EXCHANGE IF DEFECTIVE.
